Case Studies: Defence Sector
Ship and Submarine Systems
Teddingon have provided engineering solutions for submaries, minesweepers, frigates, and aircraft carriers including:
- New equipment development and deployment
- Management services for old equipment
- Installation, servicing, maintenance, and support
- Diagnostics and fault rectification
- Reverse engineering and obsolescence management
(Note: Images on this page are AI generated and are not intended to be accurate depictions of specific classes of vessel.)
Equipment Training
We provide each ship with manuals for the operation and basic setting up of all Teddington panels or other equipment on board. We also provide a variety of training services.
- General Features, Usage and Maintenance
- Fault finding and diagnostics techniques
- On-Board repair, reconfiguration and rectification techniques
Vanguard Class Submarines
We have supplied the following equipment and services for Vanguard Class submarines.
- Full control systems for the diesel power generators including integration with ships control system and safety interlocks.
- Local control panels for the HP air-compressors, sited in the main engine compartments. Additional remote panels sited outside the engine room.
- Remote access from the main ships control centre.
- Full on-board commissioning and testing including checking of ships wiring systems and calibration of temperature, pressure and speed sensors.
Victoria Class Submarines
We have supplied the following equipment and services for Victoria Class submarines.
- Full upgrade to the ships propulsion control system.
- Removal of old technology panels and replaced with units fit for servicing until 2042.
- Includes integration with ships control system and safety interlocks.
- Capability to allow additional connectivity for remote displays.
- Scalable interface to integrate with other, previously isolated, systems.
- Remote access and control from the main ships control centre.
- On-board self-test and diagnostics capability.
- Full on-board commissioning and testing including checking of ships wiring systems and calibration of temperature, pressure and speed sensors.
Hunt Class Minesweepers
We have supplied the following equipment and services for Hunt Class minesweepers.
- Salvage generator replacement project. (Provides emergency power to vessel.)
- Working with Caterpillar on the complete replacement system to the salvage generator system
- Includes control panel for start-up, control and health monitoring.
- Integration into the ships MCAS system allowing full surveillance in the ships control centre.
- Full upgrade, set-up, calibration and commissioning.
This project delivered a specialist system for ships with high levels of electro-magnetic sensitivity.
Type-23 Class Frigate
We have supplied the following equipment and services for Type-23 Class Frigates.
- Micro processor based control panel for the monitoring, surveillance and management of the high pressure air system.
- Controls and monitors all ships high-pressure air systems up to 280 Bar.
- Manages compressor loading and condensation systems, especially during high duty cycle operations.
- Working with other suppliers for refitting of compressors.
- Full upgrade, set-up, calibration and commissioning.
Invincible Class Aircraft Carriers
We have supplied the following equipment and services for Invincible Class Aircraft Carriers.
- Chilled Water Plant Control Panels:
To monitor 440V, 540kW compressor chilled water plant - High Pressure Air System:
Control panels for the surveillance system monitoring ships HP Air Compressors. Local and Remote surveillance of essential temperatures and pressures. - Refrigeration Plant:
Management of the Lightfoot refrigeration system. Monitoring differential 4-20mA Pressure and Temperature transmitters. - Full commissioning and ongoing preventative maintenance.
